Product description

The shell is made of food-grade and sanitary engineering plastics. The operation buttons and display adopt advanced ergonomics design and form an angle of 30° with the horizontal, which is not only convenient for checking the running status, but also for button operation, which makes the operator more comfortable. The product is widely used in the pharmaceutical industry, food industry, testing institutions, universities and corporate laboratories, scientific research institutions. This product mainly considers usability, followed by aesthetics; a product with unique design ideas and excellent cost performance among similar products is also one of the products applying for appearance protection.

Features

◇ Start and stop function

◇ Clockwise and counterclockwise rotation function, LED indicates the direction of rotation

◇ Speed ​​adjustment function (speed increase and deceleration), speed display function

◇ Full-speed function (to achieve rapid filling and draining of pipelines)

◇ Communication function with upper computer (computer)

◇ External control function (standard current, voltage, pulse signal control speed; level signal control start and stop, direction)

◇ Power-down memory function

◇ Leakage and overheat protection function

◇ Different pump heads and different tube numbers can be replaced

Dimensions

Technical parameter

♢ Speed: 0.1 to 100 rpm, reversible

♢ Speed precision: 0.1 rpm

♢ Speed control: Membrane keypad cw(green light)/ ccw(blue light) control

♢ Display: 3-digit LED displays current rpm

♢ External control: Start/stop, cw/ccw control and speed control 0-5 V/10 V, 4-20 mA and 0-10KHz

♢ Communication interface: RS485

♢ Power supply: AC 90V-260 V 50/60 Hz

♢ Power consumption: ≤30 W

♢ Operating condition: Temperature 0 to 40 ℃, Relative humidity < 80%

♢ Drive weight: 2.5 kg

♢ Dimensions (L×W×H): 243×151×157 (mm)

♢ IP rating: IP 31
